Aluminum Foil

Our company specializes in the production of high-precision aluminum foil. Using high-quality A00 aluminum ingots as raw materials, and backed by advanced production equipment and a strict quality control system, we provide customized products for customers.

Air duct aluminum foil

Container aluminum foil

Air conditioning foil

Battery Aluminum Foil

Technical Requirement:

Thickness：0.08mm，0.09mm

Width：20mm-52mm（Can meet customer requirements）

Roll diameter：500mm-1100mm,Φ152 Aluminum sleeve

Technical Indicator:

Alloy temper	Thickness（mm）	Tolerance（mm）	Tensile strength（N/mm²）	Elongation（%）
8011-O	0.08	+0/-0.004	86~95	≥18
8011-O	0.09	+0.03/-0.001	86~95	≥20

Technical Requirement

Alloy temper：8011-O，8011H22

Thickness：0.07mm~0.15mm

Width：950~1260mm（Φ505 steel sleeve，Max. external diameter 1750mm）；

600~1240mm（Φ150 steel sleeve or aluminum sleeve，Max. external diameter 1200 mm）

Technical Indicator

Alloy temper	Width（mm）	Tolerance（mm）	Tensile strength（N/mm²）	Elongation（%）
8011-O	0.07~0.11	±0.003	112~120	18~24
8011-O	>0.11~0.15	±0.005	112~120	22~30
8011H22	0.07~0.11	±0.003	115~125	18~22

Technical Requirement：

Alloy temper：8011-O，8011H22

Big roll：Width 900mm~1250mm，Max. roll diameter 1750 mm，Φ505 steel sleeve

Small roll：Width 250mm~800mm（Custom available），Max. roll diameter 1200 mm，Φ150 or Φ75 aluminum sleeve

Technical Indicator：

Alloy temper	Width（mm）	Tolerance（mm）	Tensile strength（N/mm²）	Elongation （%）
8011-O	0.07~ 0.10	±0.003	112~118	18~22
	＞0.10~0.20	±0.005	112~118	22~28
	＞0.20	±0.008	112~118	28~33
8011-O （Secondary annealing）	0.10~ 0.20	±0.005	88~95	22~32
8011H22	0.07~ 0.11	±0.003	115~125	19~23
8011H22	＞0.10~0.20	±0.005	115~125	22~28

Battery aluminum foil is mainly made of alloys such as 1060, 1070, 1100, 1235, and 3003, and is commonly used as cast and rolled raw materials. It is mainly used in new energy vehicles, electric bicycles, electric energy storage, communication energy storage, and other fields.
