Photovoltaic Cable

We manufacture photovoltaic cables with self-produced high-grade oxygen-free copper inner conductors. With full industrial chain capability from electrolytic copper to cables, our products are certified by the National Wire and Cable Quality Inspection & Testing Center and ECM, and internationally accredited.

Photovoltaic Cable

Product Introduction：

Photovoltaic cables are mainly used in the DC side of photovoltaic power generation systems for series cables between photovoltaic modules, parallel cables between strings and from strings to DC distribution boxes (combiner boxes), and cables from DC distribution boxes to inverters. They can also be applied to AC application cables for connecting inverters to the power grid.

Product Features：

This series of cables have the characteristics of low resistivity, together with resistance to high temperature, low temperature, oil, acid & alkali, UV radiation. It is flame-retardant and eco-friendly.

Technical Data：

Cross Section （mm²）	Construction (±0.008) tinned copper wire （No./mm±0.008）	Conductor Max.Resistance at 20℃（Ω/km）	Insulation Material	Insulation Thickness		Insulation OD.(±0.15mm）（mm±0.15）	Jacket Material	Jacket Thicknss		Cable OD.(±0.2mm）（mm±0.2）
Cross Section （mm²）		Conductor Max.Resistance at 20℃（Ω/km）	Insulation Material	Avg.	Min.	Insulation OD.(±0.15mm）（mm±0.15）	Jacket Material	Avg.	Min.	Cable OD.(±0.2mm）（mm±0.2）
1×2.5	49/0.25	7.98	XLPO	0.7	0.53	3.60	XLPO	0.8	0.58	5.4
1×4	56/0.283	5.09		0.7	0.53	3.90		0.8	0.58	5.6
1×6	84/0.283	3.39		0.7	0.53	4.60		0.8	0.58	6.4
1×10	142/0.283	1.95		0.7	0.53	5.80		0.8	0.58	7.8
1×16	228/0.283	1.24		0.7	0.53	7.00		0.8	0.58	9.3
